Keyed Drill Chuck 0.512" Cap., CAT50 Mount Size, Steel
| Item | Drill Chuck |
|---|---|
| Chuck Type | Keyed |
| Material | Steel |
| Bearing Type | Plain |
| Capacity Max. | 0.512 in |
| Capacity Min. | 0.039 in |
| Mounting Size | CAT50 |
| Nominal Capacity | 1/2 in |
| Includes | Hex Key |
| Mounting Type | CAT V Flange Mount |
| Key Number | HX-13-16 |
| Overall Length | 3-13/16 in |
| Application | CNC Machines for Milling/Drilling/Reaming/Tapping |
| Material - Machining | High Speed Steel |
| Features | Maximum 8000 rpm Without Balancing |
| For Use With | High-Speed CNC Machines |
| Max. Drill Capacity | 1/2 in |
| Keying | Keyed |
| Compatible Mfr. Model Number | Key HX-13-16 |
| Min. Drill Capacity | 1/32 in |
| Product Type | Drill Chuck |
| Type | CAT V Flange Mount |
| Compatible Tool Type | High-Speed CNC Machines |
| Compatible Drill Diameter - Minimum | 1/32 in |
| Series | HX |
| Includes Key | Key Included |
| Compatible Drill Diameter - Maximum | 1/2 in |
| Package Quantity | 1 |
