Keyless High Torque Drill Chuck 0.512" Cap., 5/8-16 Mount Size
| Item | Drill Chuck |
|---|---|
| Chuck Type | High Torque |
| Material | Steel |
| Bearing Type | Plain |
| Capacity Max. | 0.512 in |
| Capacity Min. | 0.039 in |
| Mounting Size | 5/8 in |
| Includes | Wrench |
| Key Number | Not Applicable |
| Nominal Capacity | 1/2 in |
| Mounting Type | Threaded |
| Features | Self-Tightening Mechanism Automatically Increases the Clamping Forces in proportion to the Increase in Torque during the Drilling Operation |
| Overall Length | 6.102 in |
| For Use With | Conventional or CNC Equipment |
| Max. Drill Capacity | 1/2 in |
| Min. Drill Capacity | 1/32 in |
| Application | Drill Presses With High Accuracy, Jig Bore Machines, Mills Where The Application Requires Higher Feed Rates |
| Keying | Keyless |
| Material - Machining | High Speed Steel |
| Product Type | Drill Chuck |
| Type | High Torque with Intergrated Shank |
| Compatible Drill Diameter - Minimum | 1/32 in |
| Turn Direction | CW |
| Includes Arbor | Arbor Included |
| Compatible Drill Diameter - Maximum | 1/2 in |
| Series | JK-Solid |
| Includes Wrench | Wrench Included |
| Includes Key | Key Not Included |
| Package Quantity | 1 |
