Uses (3) ADKX 1705.. Inserts, Through Coolant, 10" OAL
| Cutting Diameter | 1-1/2 |
|---|---|
| Overall Length (Decimal Inch) | 10.0000 |
| Overall Length (Inch) | 10 |
| Maximum Depth of Cut (Decimal Inch) | 0.6500 |
| Shank Type | Cylindrical |
| Shank Diameter (Decimal Inch) | 1.2500 |
| Shank Diameter (Inch) | 1-1/4 |
| Insert Holding Method | Screw |
| Series | Univex |
| Lead Angle | 0 |
| Shank Length (Decimal Inch) | 8.2800 |
| Head Length (Decimal Inch) | 1.72 |
| Rake | Positive |
| Insert Compatibility | ADKX 1705.. |
| UNSPSC Code | 27112803 |
| Number Of Flutes | 3 |
| Number Of Cutter Inserts | 3 |
| Coolant Through | Yes |
| Country of Origin | Germany |
| MSC Number | MSC# 42712018 |
