Construction Adhesive, E-60NC Series, Off-White, 1 gal, Pail, 1:01 Mix Ratio, 3 hr Functional Cure
| Item | Construction Adhesive |
|---|---|
| Type | Noncorrosive, Extended Work Life |
| Color | Off-White |
| For Use On | Electronics, Metal, Plastic |
| Container Size | 1 gal |
| Container Type | Pail |
| Functional Cure | 3 hr |
| Full Cure | 24 hr |
| Mixing Ratio | 1:01 |
| Shear Strength | 2,630 psi |
| Temp. Range | -65 to 250 deg F |
| Working Time | 1 hr |
| Series | E-60NC |
| Size | 6.76 fl oz |
| Epoxy Container | Dual-Cartridge |
| Structural Adhesive Type | Epoxy Adhesive |
| Epoxy Color | Black |
| Epoxy Max. Temp | 250 to 299 deg F |
| Shear Strength (PSI) | 2,630 |
| Temp. Range (F) | -65 to 250 |
| Work Life | 1 hr |
| Features | Electrically Insulating, Chemical Resistant, Environmental Resistant, Flowable, Industrial Grade |
| Standards | ASTM B117, ASTM D1002, ASTM D1706, ASTM D638 |
| Includes | Resin and Hardener |
| Resin Type | Epoxy |
| Application Method | Two-Part Dispenser |
| Minimum Viscosity | 8,000 cps |
| Cured Color | Black |
| Compatible Applicator | 218,483, 1,372,751, 2,693,822, 218,315, 2,693,824 |
| Resin Color | Black |
| Water Resistance | Not Water-Resistant |
| Tensile Strength | 6,800 psi |
| Full Cure Time | 24 hr |
| Hardener Color | Light Yellow |
| VOC Content Weight | Less than 10 g/L |
| Non-Sagging | No |
| Minimum Performance Temperature | -65 deg F |
| Included Components | Hardener, Resin |
| Primary Applications | Electronics |
| Total Volume | 200 mL |
| Alternate Product Name | Hysol E-60NC |
| Interior/Exterior | Exterior, Interior |
| Cure Method | Ambient |
| VOC Content Weight Percentage | Less Than 1% |
| Maximum Performance Temperature | 250 deg F |
| Hardness at Full Cure | 85 Shore D |
| Marine Grade | No |
| Maximum Viscosity | 8,000 cps |
| Materials Bonded | Aluminum, Metal, Nylon, Polycarbonate, Stainless Steel, Steel, Wood |
| Low Odor | No |
| Compatible Applicator (Grainger Part Number) | 6JZX1 |
| Weight | 18 oz |
| Container Type - Adhesives | Dual-Cartridge |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
