Epoxy Adhesive, U-09LV Series, Yellow, Syringe, 1:01 Mix Ratio, 3 hr Functional Cure
| Item | Epoxy Adhesive |
|---|---|
| Type | Low Viscosity, Medium Work Life |
| Color | Yellow |
| Container Type | Syringe |
| Functional Cure | 3 hr |
| Full Cure | 3 day |
| Mixing Ratio | 1:01 |
| Shear Strength | 1,146 psi |
| Temp. Range | -65 to 250 deg F |
| Working Time | 10 min |
| Series | U-09LV |
| Structural Adhesive Type | Urethane Adhesive |
| Size | 1.69 fl oz |
| Epoxy Max. Temp | 250 to 299 deg F |
| Work Life | 10 min |
| Shear Strength (PSI) | 1,146 |
| Epoxy Color | Clear |
| Epoxy Container | Dual-Cartridge |
| Temp. Range (F) | -65 to 250 |
| Standards | RoHS |
| Features | High Peel Strength, Industrial Grade, Low Viscosity |
| Resin Type | Urethane |
| Application Method | Two-Part Dispenser |
| Includes | Resin and Hardener |
| Full Cure Time | 3 days |
| Included Components | Hardener, Resin |
| Total Volume | 50 mL |
| Interior/Exterior | Interior Only |
| Low Odor | No |
| Hardener Color | Clear |
| Alternate Product Name | Hysol U-09LV |
| Compatible Applicator (Grainger Part Number) | 3NVL4 |
| Marine Grade | No |
| VOC Content Weight Percentage | 1% |
| Cure Method | Ambient |
| Hardness at Full Cure | 47 Shore D |
| Water Resistance | Not Water-Resistant |
| Maximum Viscosity | 1,000 cps |
| Maximum Performance Temperature | 250 deg F |
| Materials Bonded | Glass, Metal, Plastic |
| Tensile Strength | 2,752 psi |
| Resin Color | Clear |
| Minimum Viscosity | 1,000 cps |
| Minimum Performance Temperature | -65 deg F |
| Primary Applications | Plastics |
| Non-Sagging | No |
| Cured Color | Clear |
| Compatible Applicator | 267452; 720228 |
| VOC Content Weight | Less than 10 g/L |
| Weight | 419.2 oz |
| Product Form | Liquid |
| Container Type - Adhesives | Dual-Cartridge |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
