Instant Adhesive, 9460 Series, Clear, 0.17 oz, Bottle, 1:01 Mix Ratio, 3 hr Functional Cure
| Item | Instant Adhesive |
|---|---|
| Type | Dual Cartridge |
| Application | Bonding Surfaces Should Be Clean, Dry, and Free of Contamination. |
| Color | Clear |
| For Use On | Dual Epoxy Applicator |
| Container Size | 0.17 fl oz |
| Container Type | Bottle |
| Functional Cure | 3 hr |
| Full Cure | 3 day |
| Mixing Ratio | 1:01 |
| Shear Strength | 3,500 psi |
| Temp. Range | -65 to 250 deg F |
| Working Time | 50 min |
| Series | 9460 |
| Work Life | 50 min |
| Structural Adhesive Type | Epoxy Adhesive |
| For Use With | Dual Epoxy Applicator |
| Temp. Range (F) | -65 to 250 |
| Epoxy Max. Temp | 250 to 299 deg F |
| Epoxy Container | Dual-Cartridge |
| Size | 1.69 fl oz |
| Epoxy Color | Gray |
| Includes | Resin and Hardener |
| Application Method | Two-Part Dispenser |
| Resin Type | Epoxy |
| Characteristics | Fatigue Resistant,Impact Resistant,Peel Strength High Peel Strength,Sag Non-Sag,Thixotropic,Work Life Extended Work Life |
| Features | Easy to Mix, Easy to Dispense, Extended Worklife, Fatigue Resistant, Impact Resistant, Quick Heat Response, Resistant to Automotive Fluids, Smooth Paste |
| Cured Color | Gray |
| Interior/Exterior | Interior Only |
| Resin Color | White |
| Minimum Performance Temperature | -65 deg F |
| Marine Grade | No |
| Tensile Strength | 4,400 psi |
| VOC Content Weight Percentage | Less Than 1% |
| Standards | RoHS |
| Alternate Product Name | Loctite Hysol 9460 |
| VOC Content Weight | Less than 10 g/L |
| Water Resistance | Not Water-Resistant |
| Hardener Color | Black |
| Materials Bonded | Engineering Thermoplastic, Metal, Laminate |
| Non-Sagging | Yes |
| Primary Applications | General Purpose |
| Included Components | Hardener, Resin |
| Maximum Performance Temperature | 250 deg F |
| Full Cure Time | 3 days |
| Maximum Viscosity | 250,000 cps |
| Total Volume | 50 mL |
| Compatible Applicator (Grainger Part Number) | 3NVL4 |
| Low Odor | No |
| Hardness at Full Cure | 75 Shore D |
| Cure Method | Heat |
| Weight | 19 oz |
| Product Form | Paste |
| Container Type - Adhesives | Dual-Cartridge |
| Number of components | 2 Part |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
