Structural Adhesive, E-60HP Series, Amber, Jug, 2:01 Mix Ratio, 35 hr Functional Cure
| Item | Structural Adhesive |
|---|---|
| Type | High Performance |
| Application | Bonding |
| Color | Amber |
| For Use On | 97042, Mfr. No. 98472 |
| Container Type | Jug |
| Functional Cure | 35 hr |
| Full Cure | 24 hr |
| Mixing Ratio | 2:01 |
| Shear Strength | 4,300 psi |
| Temp. Range | -65 to 250 deg F |
| Working Time | 1 hr |
| Series | E-60HP |
| Epoxy Color | Off-White |
| Work Life | 1 hr |
| Epoxy Container | Dual-Cartridge |
| Epoxy Max. Temp | 250 to 299 deg F |
| Temp. Range (F) | -65 to 250 |
| Shear Strength (PSI) | 4,320 |
| Size | 1.69 fl oz |
| For Use With | Dual Cartridge Applicator |
| Structural Adhesive Type | Epoxy Adhesive |
| Standards | ISO 11359-2, ISO 4587, ISO 527-2, ISO 527-3, ISO 868 |
| Application Method | Two-Part Dispenser |
| Resin Type | Epoxy |
| Includes | Resin and Hardener |
| Maximum Viscosity | 45,000 cps |
| Compatible Applicator | 97,042, 98,472 |
| Features | Extended Work Life for Adjusting Parts During Assembly |
| Cure Method | Ambient |
| Hardener Color | Off-White |
| Hardness at Full Cure | 80 Shore D |
| Minimum Viscosity | 45,000 cps |
| Cured Color | Off-White |
| Full Cure Time | 24 hr |
| Non-Sagging | No |
| Alternate Product Name | E-60HP |
| Tensile Strength | 5,100 psi |
| Materials Bonded | Metal, Plastic |
| Low Odor | No |
| Maximum Performance Temperature | 250 deg F |
| VOC Content Weight Percentage | 0% |
| Primary Applications | General Purpose |
| Total Volume | 50 mL |
| Water Resistance | Not Water-Resistant |
| Marine Grade | No |
| Minimum Performance Temperature | -65 deg F |
| Included Components | Hardener, Resin |
| Resin Color | Yellow |
| Interior/Exterior | Interior Only |
| VOC Content Weight | Less than 10 g/L |
| Compatible Applicator (Grainger Part Number) | 3NVL4 |
| Container Type - Adhesives | Dual-Cartridge |
| Country of Origin (subject to change) | United States |
| Package Quantity | 1 |
