Lght Dmr, Switch Only, 120V AC, Wht
| Item - Motion Sensing and Dimming | Wireless Wall Switch |
|---|---|
| Switch Style - Motion Sensing and Dimming | Front Accessible Service Switch, Neutral-Wire Switch |
| Includes | Front Accessible Service Switch |
| Lighting Technology | Fluorescent, Halogen, Incandescent, LED |
| Communication Method - Motion Sensing and Dimming | Wireless RF |
| Switch Type - Motion Sensing and Dimming | 1-Pole, Multilocation |
| Number of Gangs | 1 |
| Operating Voltage - Motion Sensing and Dimming | 120V AC |
| Max. Capacity @ 120VAC | 3.6 A (General Purpose Fan), 6 A (CFL, LED), 720 VA (MLV), 720 W (ELV, Halogen, Incandescent) |
| Color - Motion Sensing and Dimming | White |
| Communication Method | Wireless |
| Item | Lighting Dimmer |
| Description/Special Features | Green Status LED(s) to Indicate Load Status, Indoor Use Only, Use Lutron Patented Clear Connect RF Technology |
| Wall Plate | Not included |
| Number of Buttons | 2 |
| Color | White |
| Sensing Technology | Switch Only |
| Installation Location - Motion Sensor | Wall |
| Standards | Complies with the limits for a Class B Digital Device, Pursuant to Part 15 of the FCC Rules Industry Canada Certified, cULus Listed, FCC Approved, IFTEL Certified, NEMA 410, NOM |
| Overall Height | 4.69 in |
| Overall Width | 2.94 in |
| Rated Frequency | 50/60 Hz |
| Minimum Operating Temperature | 32 deg F |
| Includes Dimming Switch | Dimming Switch Not Included |
| Compatible with Series | Caseta |
| Overall Depth | 0.31 in |
| Sensor Operation | Not Applicable |
| Installation Location | Wall |
| Coverage Angle | Not Applicable |
| Includes Wall Plate | Wall Plate Not Included |
| Neutral Required | Yes |
| Illuminated | Yes |
| Compatible with Brand | Lutron |
| Includes Motion Sensor | No |
| Load Rating @ 277V AC | Not Applicable |
| Dimming Type | No Dimming |
| Load Rating @ 120V AC | 3.6A (General Purpose Fan), 6A (CFL, LED), 720VA (MLV), 720W (ELV, Halogen, Incandescent) |
| Series | Caseta |
| Fan Rated | Yes |
| Maximum Operating Temperature | 104 deg F |
| Maximum Coverage Area | Not Applicable |
| Nightlight | No |
| Dimming Method | No Dimming |
| Maximum Wattage | 720W Lighting; 3.6A General Purpose Fan |
| Coordinating Wallplates | Single Gang Wallplate CW-1-XX ; 2-Gang Wallplate CW-2-XX |
| Application Type | Single-Pole or Multi-Location w/Pico(s) |
| Bulb Compatibility | CFL/LED, Fluorescent, Incandescent/Halogen, ELV, MLV, General Purpose Fan |
| Package Quantity | 1 |
