Collet Jet Slots, MMC12, 12mm
| Item | Collet |
|---|---|
| Collet Series | VMK12 |
| Range | Exact Size |
| Size | 12.00mm |
| For Use With | Collet Chucks |
| Coolant Through | No |
| Coolant Fed | Non-Coolant Through |
| Measurement System | Metric |
| Compatible with Product Type | MMC12 Mini Chuck |
| Collet Type | Rigid |
| Face Shape | Round |
| Number of Slots | 3 |
| Overall Length | 2-13/64 in |
| Min. Size | 12 mm |
| Features | Collet Slots Allow Coolant to be Supplied Directly to the Periphery of the Cutting Tool, Coolant Along the Periphery of the Cutting Tool will also Help Flush Out Chips, During Pocket Milling Operations |
| Max. Body Dia. | 12 mm |
| Head Dia. | 21 mm |
| Collapse Range - Maximum | 12 mm |
| Bore Shape | Round |
| Outside Diameter - Maximum | 0.827 in |
| Compatible Collet Chuck | MMC Collet Chucks |
| Package Quantity | 1 |
