ER Tapping Collet, ER16, 0.255x0.191in
| Item | Rigid Tap Collet |
|---|---|
| Collet Series | ER16 |
| Size | 0.255" x 0.191" |
| For Use With | ER Collet Chucks |
| Coolant Through | No |
| Tap Size | #14, 1/4", M6, M6.5 |
| Coolant Fed | Non-Coolant Through |
| Features | ER Tap Collets Feature a Unique Design that Incorporates an Internal Square Drive with Our Popular ER Series Collets, The Square Drive Matches the Tap Square, Providing a Tight Fit for all Rigid Tapping Applications |
| Measurement System | Inch |
| Number of Slots | 8 |
| Face Shape | Round |
| Compatible with Product Type | ER Collet Chucks |
| Clamping Hole Length | 7/8 in |
| Max. Body Dia. | 0.255 in |
| Collet Type | Tap |
| Overall Length | 1-1/16 in |
| Product Type | Rigid Tap Collet |
| Tap Square Size | 0.191 in |
| Series | ER16 |
| Tap Size - Millimeters - Maximum | M6.5 |
| Quick-Change Status | Not Quick-Change |
| Tap Shank Diameter | 0.255 in |
| Tap Size - Inches - Minimum | Not Applicable |
| Tap Size - Inches - Maximum | 1/4 in |
| Outside Diameter - Maximum | 0.67 in |
| Tap Size - Millimeters - Minimum | M6 |
| Compatible Tap Holder | ER Collet Chucks |
| Package Quantity | 1 |
