Milling Chuck Holder, HSK63, Nose 2.047in
| Collet Series | KM3/4 |
|---|---|
| Taper Size | CAT50 |
| Nose Dia. | 2.04 in |
| Item | Milling Chuck |
| Projection | 6 in |
| Coolant Through | Yes |
| Hole Dia. | 3/4 in |
| Bore Depth | 2.688 in |
| Coolant Fed | Coolant Through |
| Clamping Range | 1/8 to 3/4 in |
| Features | 140% More Bearing Surface than Competitor Milling Chucks;For Quiet and Stable Heavy Milling;Nikken Patented Design;Nut Body Contact, Nose Clamping and Anti-Vibration Mechanism;Thick Body and Internal Slots Provide Extremely Strong Chucking Torque and Rigidity |
| TIR Max. | Less Than 0.0002 in |
| Product Type | Milling Chuck |
| Finish | Black Oxide |
| Compatible Reducing Sleeve | KM3/4 |
| Nose Diameter | 2-3/4 in |
| Coolant Supply | Coolant Through |
| Measurement System | Inch |
| Package Quantity | 1 |
