End Mill, 1/4" Dia, 3/4" Cut, Carbide
| Dimension Type | Fractional Inch |
|---|---|
| Milling Diameter | 1/4 in |
| End Mill Material | Carbide |
| Number of Flutes | 2 |
| Length of Cut | 3/4 in |
| Single End/Double End | Single End |
| End Mill Cutting Type | Center Cutting |
| Grade | High Performance |
| Shank Dia. | 1/4 in |
| Overall Length | 2-1/2 in |
| List Number | 136 |
| Cast Iron (K) Compatibility | No |
| Helix Angle | 45 deg |
| Shank Type | Straight |
| End Mill Application | Finishing |
| Stainless (M) Compatibility | No |
| Non Ferrous (N) Compatibility | Yes |
| Cutting Direction | Right Hand |
| Measurement System | Fractional Inch |
| Milling Dia. | 1/4 in |
| Hardened (H) Compatibility | No |
| Finish - Machining | Bright |
| Steel (P) Compatibility | No |
| Item | Square End Mill |
| Finish | Bright |
| Shank Type - Machining | Straight |
| End Mill Style | Square |
| Super Alloy (S) Compatibility | No |
| Material Grade - Machining | High Performance |
| Package Quantity | 1 |
