39-34961 RECEPTACLE
| Body Material - Pin and Sleeve | Zamak |
|---|---|
| Amps - Plugs and Receptacles | 50 A |
| Voltage | 600V AC/130V DC |
| Color - Plugs and Receptacles | Gray |
| Contact Configuration | 6 P+G |
| Number of Aux. Outputs | NO AUX |
| Impact Rating | IK09 |
| Wire Size | 14 AWG to 8 AWG |
| Operating Temp. Range | -40C to 60C |
| Terminal Type | Screw terminal |
| Tightening Torque | Phase: 15 IN-LBS / 1.7 N-M |
| Color Code | Black |
| Keying Position | 9 |
| Hz | 60 Hz |
| Use With Installation Accessory Size | 4 |
| Wire Strip Length | Phase: 1-1/16 in |
| IP Rating | IP54/55 |
| Package Quantity | 1 |
