Receptáculo de clavija y enchufe, con capacidad de 2 A a 7.5 A y voltaje de 600V AC, diseñado con 3 polos para una conexión segura y confiable.
| Item | Pin & Sleeve Receptacle |
|---|---|
| Current Rating | 2 A/7.5 A |
| Voltage Rating | 600V AC |
| Number of Poles | 3 |
| Number of Wires | 4 |
| IP Rating | IP67, IP66 |
| Housing Color | Metal |
| Cap Type | No Cap or Cover |
| Use With | Mating Box MB3 |
| Voltage | 600V AC/130V DC |
| Body Material | Zamak |
| Terminal Type | Solder/Crimp terminal |
| Hz | 60 Hz |
| Use With Installation Accessory Size | 1 |
| Operating Temp. Range | -40C to 60C |
| Wire Strip Length | Phase: 25/64 in |
| Load Break Amp Rating | 2 A |
| Keying Position | 1 |
| Impact Rating | IK08 |
| Number of Notch Positions | 2 |
| Color Code | Blue |
| Contact Configuration | 11 P+G |
| Wire Size | 18 AWG to 14 AWG |
| Package Quantity | 1 |
