Automotive Fuse, A70P Series, 40A, 650V DC
| Item | Automotive Fuse |
|---|---|
| Series | A70P |
| Speed | Very Fast Acting |
| Amps | 40A |
| DC Voltage Rating | 650V DC |
| AC Voltage Rating | 700V AC |
| Interrupt Rating | 65kA |
| Body Style | Blade |
| Body Material | GMG |
| Length | 4.38 in |
| Equivalent Brand and Series | Mersen |
| Equivalent Series | A70P, FWP, L70QS |
| APPROVALS & STANDARDS | UL recognized component UL File E60314; AC: guide no. JFHR2 (10-1000A); DC: tested to UL standard 198L parameters (10-800A) |
| AC Max I.R./Breaking Capacity: I1 | 65 kA |
| Connection/Terminal Type | Bolted |
| Mounting | Bolted |
| Body/Insulating Material | GMG |
| Connection/Terminal Material | Tin-Plated Brass |
| APPLICATIONS | Protection of 700V or less DC drives, UPS, inverters, reduced voltage starters, etc. |
| Package Quantity | 1 |
