Automotive Fuse, A70QS Series, 500A, 700V DC, Non-Indicating
| Item | Automotive Fuse |
|---|---|
| Series | A70QS |
| Speed | Very Fast-Acting |
| Amps | 500A |
| DC Voltage Rating | 700V DC |
| AC Voltage Rating | 700V AC |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 40kA |
| Body Style | Blade |
| Body Material | GMG |
| Length | 7.09 in |
| Equivalent Brand and Series | A70QS, Bussmann FWP, Littelfuse L70QS, Mersen A70P |
| Equivalent Series | A70P, A70QS, FWP, L70QS |
| Fits Fuse Block Style | Non-Rejection |
| APPLICATIONS | Protection of 700V or less motor drives, UPS, inverters, etc. |
| AC Max I.R./Breaking Capacity: I1 | 40 kA |
| APPROVALS & STANDARDS | UL recognized component, AC/DC UL file E60314; AC: guide no. JFHR2; DC: tested to UL standard 198L parameters (35-800A); CSA certified File LR 12636 |
| Mounting | Bolted |
| Connection/Terminal Type | Bolted |
| Connection/Terminal Material | Copper |
| Body/Insulating Material | GMG |
| Package Quantity | 1 |
