Forklift Limiter Fuse, CNL Series, 125A, Time-Delay, 80V AC, Bolt-On
| Item | Forklift Limiter Fuse |
|---|---|
| Series | CNL |
| Amps | 125A |
| Speed | Time-Delay |
| AC Voltage Rating | 80V AC |
| DC Voltage Rating | 80VDC |
| Body Style | Bolt-On |
| Visual Indication | Indicating |
| Interrupt Rating | 2.5kA at 80VAC, 2.5kA at 80VDC |
| Body Material | Fiberglass |
| Diameter | Not-Applicable |
| Length | 3-3/16 in |
| Equivalent Brand and Series | Bussmann ANL, Littelfuse CNL, Mersen CNL |
| Equivalent Series | ANL, CNL |
| Fits Fuse Block Style | Non-Rejection |
| Rated voltage DC UL | 80 V |
| Standards | UL Recognized Component To Standard 248-1, File E60314 JFHR2 |
| Mounting | Bolted |
| Element | Single |
| Frequency | 50/60 Hz |
| Body/Insulating Material | GMG |
| Indication System | Yes |
| Width | 3/4 in |
| APPROVALS & STANDARDS | UL recognized components (All Products) File E60314 |
| Product Height | 0.63 in |
| AC Max I.R./Breaking Capacity: I1 | 2,500 A |
| Indication System Type | Visual Indicator |
| Depth | 13/32 in |
| Connection/Terminal Material | Silver-Plated Copper |
| Connection/Terminal Type | Blade |
| Connection Type | Blade |
| APPLICATIONS | Forklift trucks; Battery hand trucks; Motorized work platforms; Battery systems |
| Product Width | 0.63 in |
| Package Quantity | 1 |
