Fuse Link, RL Series, 100A, Fast-Acting, 250V AC
| Item | Fuse Link |
|---|---|
| Series | RL |
| Amps | 100A |
| Speed | Fast-Acting |
| AC Voltage Rating | 250V AC |
| DC Voltage Rating | Not Rated |
| Length | 3.03 in |
| Fuse Amps | 100 A |
| Class | H |
| Fuse Voltage Rating | 250 V |
| Fuse Class | Class H |
| Rated voltage AC UL | 250 V |
| Ampere Rating | 100 A |
| APPROVALS & STANDARDS | UL listed to standard 248-7 File E2137; CSA certified to standard C22.2 no. 248.7 |
| Frequency | 50/60 Hz |
| Product Width | 0.66 in |
| APPLICATIONS | General purpose loads where short circuits are 10,000 amperes or less |
| Package Quantity | 1 |
