Medium-Voltage Fuse, BDE Series, 1A, 8250V AC, Cylindrical
| Item | Medium-Voltage Fuse |
|---|---|
| Series | BDE |
| Amps | 1A |
| AC Voltage Rating | 8250V AC |
| DC Voltage Rating | Not Rated |
| Body Style | Cylindrical |
| Visual Indication | Indicating |
| Interrupt Rating | 50kA |
| Body Material | Epoxy |
| Diameter | 1.56 in |
| Length | 9-1/2 in |
| Fuse Amps | 1 A |
| Fuse Voltage Rating | 8,250 V |
| Connection Type | Ferrule |
| Mounting | Clip |
| Connection Material | Copper |
| Storage Temp. Range | -25 to 80 °C |
| Operating Temp. Range | 80 °C |
| Body/Insulating Material | Epoxy |
| Ampere Rating | 1 A |
| Connection/Terminal Material | Copper |
| APPLICATIONS | Primary protection for potential transformers (PT) or control power transformers (CPT) |
| AC Max I.R./Breaking Capacity: I1 | 50 kA |
| Connection/Terminal Type | Ferrule |
| Rated voltage AC UL | 8,250 V |
| Package Quantity | 1 |
