Medium-Voltage Fuse, FPK Series, 1A, E-Rated, 38000V AC, Cylindrical
| Item | Medium-Voltage Fuse |
|---|---|
| Series | FPK |
| Amps | 1A |
| Speed | E-Rated |
| AC Voltage Rating | 38000V AC |
| DC Voltage Rating | Not Rated |
| Body Style | Cylindrical |
| Visual Indication | Indicating |
| Interrupt Rating | 26kA |
| Body Material | Epoxy |
| Diameter | 3 in |
| Length | 30.81 in |
| Class | E |
| Fuse Voltage Rating | 38,000 V |
| Fuse Speed | E-Rated |
| Fuse Amps | 1 A |
| Operating Temp. Range | 80 °C |
| Mounting | Clip |
| Storage Temp. Range | -25 to 80 °C |
| Connection Type | Ferrule |
| Connection Material | Silver-Plated Copper |
| Body/Insulating Material | Epoxy |
| Connection/Terminal Material | Silver-Plated Copper |
| APPROVALS & STANDARDS | Some UL listed to standard File E143362 |
| Ampere Rating | 1 A |
| Connection/Terminal Type | Ferrule |
| AC Max I.R./Breaking Capacity: I1 | 26 kA |
| APPLICATIONS | Protection for 26 kV to 38 kV transformers or distribution systems. |
| Rated voltage AC UL | 38,000 V |
| Package Quantity | 1 |
