Medium-Voltage Fuse, HP10J Series, 160A, Fast-Acting, 600V AC, Blade
| Item | Medium-Voltage Fuse |
|---|---|
| Series | HP10J |
| Amps | 160A |
| Speed | Fast-Acting |
| AC Voltage Rating | 600V AC |
| DC Voltage Rating | 1000V DC |
| Body Style | Blade |
| Interrupt Rating | 200kA |
| Body Material | GMG |
| Diameter | 1.63 in |
| Length | 5-3/4 in |
| Fuse Voltage Rating | 1,000 V |
| Class | G PV |
| Fuse Amps | 160 A |
| Fuse Speed | gPV |
| Fuse Class | Photovoltaic |
| Mounting | Clip, Bolted |
| Storage Temp. Range | -25 to 80 °C |
| Connection Material | Brass |
| Connection/Terminal Type | Blade |
| APPROVALS & STANDARDS | UL listed to UL listed to Standard 248; File E333668 (70A to 600A); File E2137 (70A to 400A); CSA Component Certified C22.2 (70A to 400A) |
| Ampere Rating | 160 A |
| Frequency | 50/60 Hz |
| Connection/Terminal Material | Brass |
| Rated voltage DC UL | 1,000 V |
| APPLICATIONS | Re-combiner box (sub-combiner, array combiner, master combiner) applications; Inverter DC input; Battery charge controllers |
| Body/Insulating Material | GMG |
| AC Max I.R./Breaking Capacity: I1 | 200 kA |
| Rated voltage AC UL | 600 V |
| Package Quantity | 1 |
