Midget Fuse, HP10M Series, 25A, 1000V AC, 10kA
| Series | HP10M |
|---|---|
| Amps | 25A |
| AC Voltage Rating | 1000V AC |
| Interrupt Rating | 10kA |
| Body Style | Cylindrical |
| Diameter | 1-1/2 in |
| Length | 0.41 in |
| Body Material | GMG |
| DC Voltage Rating | 1000V DC |
| Item | Midget Fuse |
| Class | gPV |
| Storage Temp. Range | -25 to 80°C |
| Connection Material | Tin-Plated Copper |
| Mounting | Clip |
| AC Max I.R./Breaking Capacity: I1 | 50 kA |
| APPROVALS & STANDARDS | UL Listed to Standard UL2579 File E333668; CSA Component Certified C22.2; IEC 60269-6 Approved (CB Tested) |
| Frequency | 50/60 Hz |
| Connection Type | Ferrule |
| Package Quantity | 1 |
