Bloque de distribución de energía, 1 polo, rango de amperaje de 240A, clasificación de voltaje de 1000V CA/CC.
| Item | Power Distribution Block |
|---|---|
| Number of Poles | 1 |
| Connector Type | Screw |
| Mounting Style | Bolt-Down |
| Voltage Rating | 1000V AC/DC |
| Body Material | GFPC |
| Height | 2.81 in |
| Length | 3.08 in |
| Fuse UL Class | UL1953 Open-style |
| Series | MPDB |
| Features | All sizes have optional adder poles for increased flexibility and ease-of-use. Adder poles allow for customization of primary and secondary wire combinations. |
| Width | 1.05 in |
| Max. Operating Temp. | 80 deg C |
| Short Circuit Rating (Class CC) | 30 kA |
| APPROVALS & STANDARDS | UL Listed to subject 1953, File E352417 unless noted otherwise; CSA Certified Class 6228 01 |
| Short Circuit Rating (Class RK5) | 30 kA |
| Short Circuit Rating (Class L) | 200 kA |
| Number of Openings per Pole (Primary) | 1 |
| Short Circuit Rating (Class J) | 200 kA |
| Short Circuit Rating (Class RK1) | 100 kA |
| Short Circuit Rating (Standalone) | 10 kA |
| Short Circuit Rating (Class G) | 60 kA |
| Connector Material | Tin-plated Copper |
| Short Circuit Rating (Class T) | 200 kA |
| Package Quantity | 1 |
