Bloque de distribución de energía, 3 polos, rango de amperaje de 310 a 380A, calificación de voltaje de 1000V CA/CC.
| Item | Power Distribution Block |
|---|---|
| Number of Poles | 3 |
| Amp Range | 310 to 380 A |
| Connector Type | Box Lug |
| Mounting Style | Screw |
| Voltage Rating | 1000V AC/DC |
| Wire Range | 4 AWG to 500 MCM |
| Body Material | GFPC |
| Height | 3-1/4 in |
| Series | MPDB |
| Length | 5 in |
| Width | 5.28 in |
| Fuse UL Class | UL1953 Open-style |
| Features | All sizes have optional adder poles for increased flexibility and ease-of-use. Adder poles allow for customization of primary and secondary wire combinations. |
| Max. Operating Temp. | 80 deg C |
| Short Circuit Rating (Class G) | 60 kA |
| Hex/Screw Size & Type (Primary) | 13/16-16 x 1.06 |
| APPROVALS & STANDARDS | UL Listed to subject 1953, File E352417 unless noted otherwise; CSA Certified Class 6228 01 |
| Short Circuit Rating (Class CC) | 30 kA |
| Number of Openings per Pole (Primary) | 1 |
| Connector Material | Tin-plated Aluminum |
| Short Circuit Rating (Standalone) | 10 kA |
| Short Circuit Rating (Class J) | 400 kA |
| Hex/Screw Size & Type (Secondary) | 13/16-16 x 1.06 |
| Short Circuit Rating (Class T) | 400 kA |
| Short Circuit Rating (Class RK1) | 200 kA |
| Short Circuit Rating (Class RK5) | 100 kA |
| Short Circuit Rating (Class L) | 400 kA |
| Mounting Hole Dia. | 0.88 in |
| Package Quantity | 1 |
