Power Distribution Block, 3 Poles, 620 to 760A Amp Range, 1000V AC/DC Volt Rating
| Item | Power Distribution Block |
|---|---|
| Number of Poles | 3 |
| Amp Range | 620 to 760 A |
| Connector Type | Screw |
| Mounting Style | Bolt-Down |
| Voltage Rating | 1000V AC/DC |
| Wire Range | 4 AWG to 500 MCM |
| Body Material | GFPC |
| Height | 3.55 in |
| Length | 5.7 in |
| Fuse UL Class | UL1953 Open-style |
| Features | All sizes have optional adder poles for increased flexibility and ease-of-use. Adder poles allow for customization of primary and secondary wire combinations. |
| Width | 7.89 in |
| Series | MPDB |
| Max. Operating Temp. | 80 deg C |
| Hex/Screw Size & Type (Primary) | 13/16-16 x 1.06 |
| Number of Openings per Pole (Primary) | 2 |
| Short Circuit Rating (Standalone) | 10 kA |
| APPROVALS & STANDARDS | UL Listed to subject 1953, File E352417 unless noted otherwise; CSA Certified Class 6228 01 |
| Connector Material | Tin-plated Aluminum |
| Mounting Hole Dia. | 0.88 in |
| Package Quantity | 1 |
