Semiconductor Fuse, A120X Series, 10A, Fast-Acting, 1200V AC, Ferrule
| Item | Semiconductor Fuse |
|---|---|
| Series | A120X |
| Amps | 10A |
| Speed | Fast-Acting |
| AC Voltage Rating | 1200V AC |
| DC Voltage Rating | 1000V DC |
| Body Style | Ferrule |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 200kA |
| Body Material | GMG |
| Diameter | 0.81 in |
| Length | 4.63 in |
| Equivalent Brand and Series | Bussmann FWS |
| Equivalent Series | FWS |
| Fits Fuse Block Style | Non-Rejection |
| Fuse Speed | High Speed |
| Mounting | Clip |
| Connection Material | Tin-Plated Copper |
| Ampere Rating | 10 A |
| Connection/Terminal Material | Tin-Plated Copper |
| APPROVALS & STANDARDS | UL recognized component File E 60314 |
| APPLICATIONS | Protection of traction drive auxiliary circuits, etc. |
| AC Max I.R./Breaking Capacity: I1 | 200 kA |
| Package Quantity | 1 |
