Semiconductor Fuse, A70P Series, 150A, Fast-Acting, 700V AC, Bolt-On
| Item | Semiconductor Fuse |
|---|---|
| Series | A70P |
| Amps | 150A |
| Speed | Fast-Acting |
| AC Voltage Rating | 700V AC |
| DC Voltage Rating | 650V DC |
| Body Style | Bolt-On |
| Visual Indication | Indicating |
| Interrupt Rating | 50kA |
| Body Material | GMG |
| Diameter | 1-1/2 in |
| Length | 5.09 in |
| Equivalent Brand and Series | Bussmann FWP, Littelfuse L70QS, Mersen A70P |
| Equivalent Series | FWP, A70P, L70QS |
| Fuse Speed | High Speed |
| Connection Material | Brass |
| Mounting | Bolted |
| AC Max I.R./Breaking Capacity: I1 | 50 kA |
| APPROVALS & STANDARDS | UL recognized component UL File E60314; AC: guide no. JFHR2 (10-1000A); DC: tested to UL standard 198L parameters (10-800A) |
| APPLICATIONS | Protection of 700V or less DC drives, UPS, inverters, reduced voltage starters, etc. |
| Indication System Type | TA Indicator |
| Connection/Terminal Material | Brass |
| Ampere Rating | 150 A |
| Package Quantity | 1 |
