Stud Pair, 1500V AC/DC Volt Rating, 1 Poles, Stud, Semiconductor Fuse Fuse Type
| Item | Stud Pair |
|---|---|
| Voltage Rating | 1500V AC/DC |
| Number of Poles | 1 |
| Connector Type | Stud |
| Fits Fuse Type | Semiconductor Fuse |
| Mounting Style | Screw |
| Width | 2.45 in |
| Length | 1.87 in |
| Fuse Type | 1SC |
| Height | 0.7 in |
| Series | 1SC |
| Body Material | Thermoplastic |
| Frequency Range (Hz) | 50/60 Hz |
| Short Circuit Current (KA) | 200 kA |
| Rated Torque (In.-Lb.) | 61 in-lb |
| Max. Operating Temp. | 80 deg C |
| Fuse Installation Method | Bolt-in |
| Short Circuit Current Rating (SCCR) | 200 kA |
| Frequency | 50/60 Hz |
| Max Fuse Rating | 400 A |
| Installation Mounting | Direct Screw Mount |
| APPLICATIONS | 1500VAC/DC, 800A Maximum, Modular semiconductor fuse blocks; 1000VAC/DC |
| APPROVALS & STANDARDS | UL Recognized Component File E52283 |
| Short Description | Fuse Bases 1500V 400A Semiconductor 1-pole 1/4 inch Stud |
| Torque Rating | 61.0002 in-lb |
| Max. Voltage | 1500V AC/DC |
| Max. Amps | 400 |
| Package Quantity | 1 |
