UL Class Fuse, G Class, AG Series, Fast-Acting, 5A, 600V AC, Non-Indicating
| Class | G |
|---|---|
| Series | AG |
| Speed | Fast-Acting |
| Amps | 5A |
| AC Voltage Rating | 600V AC |
| DC Voltage Rating | Not Rated |
| Visual Indication | Non-Indicating |
| Interrupt Rating | 100kA at 600V AC |
| Body Style | Cylindrical |
| Body Material | GMG |
| Length | 1.31 in |
| Diameter | 0.41 in |
| Equivalent Brand and Series | Bussmann SC, Littelfuse SLC, Mersen AG |
| Equivalent Series | AG, SC, SLC |
| Fits Fuse Block Style | Rejection |
| Item | UL Class Fuse |
| Element | Single |
| Mounting | Clip |
| Connection Material | Tin-Plated Copper |
| Weight | 0.02 lb |
| Standards | CSA Certified to C22.2 No. 248.5, UL Listed 248-5 |
| APPROVALS & STANDARDS | UL listed to standard 248-5 File E2137; CSA certified to standard C22.2 No. 248.5 |
| Green Environmental Attribute | RoHS 2011/65/EU Compliant |
| AC Max I.R./Breaking Capacity: I1 | 100 kA |
| Fuse Speed | Fast Acting |
| Short Description | Series |
| Connection/Terminal Material | Tin-Plated Copper |
| Package Quantity | 1 |
