UL Class Fuse, J Class, A4J Series, Fast-Acting, 600A, 600V AC
| Class | J |
|---|---|
| Series | A4J |
| Speed | Fast-Acting |
| Amps | 600A |
| AC Voltage Rating | 600V AC |
| DC Voltage Rating | 300V DC |
| Interrupt Rating | 200kA at 600V AC, 100kA at 300V DC |
| Body Style | Blade |
| Body Material | GMG |
| Length | 8 in |
| Diameter | 2-1/2 in |
| Item | UL Class Fuse |
| Fuse Speed | Fast Acting |
| Weight | 3.2 lb |
| Mounting | Clip |
| Connection Material | Brass Alloy |
| Connection/Terminal Material | Brass Alloy |
| AC Max I.R./Breaking Capacity: I1 | 200 kA |
| APPROVALS & STANDARDS | UL listed to standard 248-8 File E2137; CSA certified to standard C22.2 no. 248.8; DC listed to UL 248; IEC 269-2-1 |
| Short Description | Fuse Amp- Series |
| Package Quantity | 1 |
