Fixture Clamps, Cam Action, M12, 25mm, PK8
| Item | Fixture Clamp |
|---|---|
| Clamp Style | Cam Action |
| Thread Size | M12 |
| Thread Length | 25 mm |
| For Use With | Workholding |
| Drive Size | 8 mm |
| Diameter | 12 mm |
| Material | Brass/Steel |
| Overall Width | Not Applicable |
| Overall Height | 32.32 mm |
| Holding Force | 17,790 N |
| Slot Size | 25.38 mm |
| Clamp Type | Fixture Clamp |
| Features | Low Profile, Simple Design |
| Application | Workholding |
| Workpiece Tapping Distance | 12.7 mm |
| Head Height | 9.52 mm |
| Clamp Movement - Maximum | 2.03 mm |
| Series | Not Applicable |
| Step Height | Not Applicable |
| Measurement System | Metric |
| Machinable Width - Maximum | Not Applicable |
| Number of Clamps | 8 |
| Clamping Face Material | Brass |
| Overall Length | Not Applicable |
| Bolt Thread Size | M12 |
| Clamp Body Slot Length | Not Applicable |
| Clamp Face Type | Smooth |
| Clamp Body Material | Steel |
| Head Width | 25.38 mm |
| T-Slot Width | Not Applicable |
| Step Depth | Not Applicable |
| Bolt Thread Length | 25 mm |
| Clamping Force - Maximum | 17,790 N |
| Package Quantity | 8 |
