Knife Edge Clamps, Cam Action, 1/2-13, PK8
| Item | Fixture Clamp |
|---|---|
| Clamp Style | Cam Action |
| Thread Size | 1/2"-13 |
| Thread Length | 1 in |
| Overall Height | 1.275 in |
| Overall Width | 1 in |
| Drive Size | 5/16 in |
| Holding Force | 4000 lb |
| Material | Steel |
| Diameter | 1/2 in |
| For Use With | Workholding |
| Material - Machining | Steel |
| Features | Low Profile |
| Application | Workholding |
| Clamp Type | Fixture Clamp |
| Head Width | 1 in |
| Workpiece Tapping Distance | 1/2 in |
| Clamping Force - Maximum | 17,790 N |
| Clamp Body Slot Length | Not Applicable |
| Series | Not Applicable |
| Clamp Face Type | Knife |
| Number of Clamps | 8 |
| Overall Length | Not Applicable |
| Step Height | Not Applicable |
| Step Depth | Not Applicable |
| Measurement System | Inch |
| Machinable Width - Maximum | Not Applicable |
| Head Height | 3/8 in |
| Clamping Face Material | Steel |
| Clamp Body Material | Steel |
| Bolt Thread Length | 0.9 in |
| Clamp Movement - Maximum | 0.08 in |
| T-Slot Width | Not Applicable |
| Head Length | Not Applicable |
| Bolt Thread Size | 1/2"-13 |
| Package Quantity | 8 |
