Conector de placa, 11 contactos, 1 fila, hembra, paso de 0.079 pulgadas, terminal de crimpado, con seguro.
| Application | Signal, Wire-to-Board |
|---|---|
| Series | 51090 |
| Gender | Receptacle |
| Product Name | Mi II |
| CSA | LR19980 |
| Number of Rows | 1 |
| Temperature Range - Operating | -40° to +105°C |
| Stackable | No |
| Color - Resin | Natural |
| Circuits (maximum) | 11 |
| Material - Resin | Polyester |
| UL | E29179 |
| Flammability | 94 V to 0 |
| Glow-Wire Capable | No |
| Pitch - Mating Interface | 2 mm |
| Package Quantity | 1 |
