Conector de placa, 12 contactos, 1 fila, macho, ángulo recto, terminal de soldadura.
| Max. Voltage | 300 V |
|---|---|
| Series | 39512 |
| Standards | UL E48521 |
| Hole Center to Center | 3.81 mm |
| Type | Block |
| Max. Temp. | 105 deg C |
| Number of Contacts | 12 |
| Number of Rows | 1 |
| Current Rating | 8 A |
| Temperature Range - Operating | -40° to +105°C |
| Shrouded | Fully |
| Pitch - Mating Interface | 3.81 mm |
| Orientation | Horizontal |
| PC Tail Length | 3.5 mm |
| Current - Maximum per Contact | 8 A |
| Lock to Mating Part | None |
| Polarized to Mating Part | Yes |
| PCB Thickness - Recommended | 2.5 mm |
| Stackable | No |
| Component Type | PCB Header |
| Circuits (Loaded) | 12 |
| Product Name | Pluggable |
| UL | E48521 |
| Package Quantity | 1 |
