Board Connector, 12 Contact(S), 1 Row(S), Male, Straight, 0.059 Inch Pitch, Surface Mount Terminal,
| Color | Black |
|---|---|
| Max. Voltage | 250V AC/DC |
| Application | Signal, Wire-to-Board |
| Series | 87437 |
| Standards | CSA Certified, UL E29179 |
| Max. Temp. | 105 deg C |
| Terminal Type | Surface Mount |
| Material | Nylon |
| Hole Center to Center | 1.5 mm |
| Number of Contacts | 12 |
| Number of Rows | 1 |
| Flammability Rating | UL 94V-0 |
| Current Rating | 2.5 A |
| Terminal Finish | Tin Plated |
| Contact Finish | Tin Plated |
| Contact Plating Thickness | 2.54 µm |
| Guide to Mating Part | No |
| Lock to Mating Part | Yes |
| Orientation | Vertical |
| Product Name | Pico-SPOX |
| Durability (mating cycles max) | 10 |
| Polarized to PCB | No |
| Temperature Range - Operating | -55° to +105°C |
| Material - Plating Termination | Tin |
| Robotic Placement | Pick and Place Cap |
| Current - Maximum per Contact | 2.5 A |
| Component Type | PCB Header |
| Material - Plating Mating | Tin |
| Keying to Mating Part | None |
| Voltage - Maximum | 250V AC (RMS)/DC |
| Plating min - Mating | 2.54 um |
| Shrouded | Fully |
| UL | E29179 |
| Circuits (Loaded) | 12 |
| PCB Retention | None |
| Glow-Wire Capable | No |
| Material - Resin | Nylon |
| First Mate / Last Break | No |
| CSA | LR19980 |
| Polarized to Mating Part | Yes |
| Pitch - Mating Interface | 1.5 mm |
| Material - Metal | Brass |
| PCB Locator | No |
| Stackable | No |
| Breakaway | No |
| Flammability | 94 V to 0 |
| Package Quantity | 1 |
