Conector de placa, 13 contactos, 1 fila, hembra, recto, paso de 0.098 pulgadas, terminal de engarce.
| Color | Natural |
|---|---|
| Application | Signal, Wire-to-Board |
| Series | 5264 |
| Standards | UL E29179 |
| Max. Temp. | 105 deg C |
| Hole Center to Center | 2.5 mm |
| Connector Type | Receptacle |
| Material | Nylon |
| Number of Contacts | 13 |
| Number of Rows | 1 |
| Flammability Rating | UL 94V-0 |
| Polarized to Mating Part | Yes |
| Glow-Wire Capable | No |
| Material - Resin | Nylon |
| Flammability | 94 V to 0 |
| Pitch - Mating Interface | 2.5 mm |
| Product Name | Mini-SPOX |
| Temperature Range - Operating | -55° to +105°C |
| UL | E29179 |
| Stackable | No |
| Lock to Mating Part | No |
| Circuits (maximum) | 13 |
| Package Quantity | 1 |
