Board Connector, 13 Contact(S), 1 Row(S), Male, Right Angle, 0.098 Inch Pitch, Solder Terminal,
| Color | Natural |
|---|---|
| Max. Voltage | 250 V |
| Application | Signal, Wire-to-Board |
| Series | 5268 |
| Standards | CSA Certified, UL E29179 |
| Material | Nylon |
| Max. Temp. | 105 deg C |
| Hole Center to Center | 2.5 mm |
| Terminal Type | Through Hole |
| Current Rating | 3 A |
| Flammability Rating | UL 94V-0 |
| Contact Finish | Tin Plated |
| Contact Plating Thickness | 4.064 µm |
| Terminal Finish | Tin Plated |
| Number of Rows | 1 |
| Number of Contacts | 13 |
| CSA | LR19980 |
| Stackable | No |
| Orientation | Right Angle |
| Temperature Range - Operating | -55° to +105°C |
| Product Name | Mini-SPOX |
| Shrouded | Fully |
| Durability (mating cycles max) | 30 |
| PCB Retention | None |
| Pitch - Mating Interface | 2.5 mm |
| PC Tail Length | 3.5 mm |
| PCB Locator | No |
| Lock to Mating Part | Yes |
| Breakaway | No |
| Guide to Mating Part | No |
| PCB Thickness - Recommended | 1.6 mm |
| Current - Maximum per Contact | 3 A |
| Plating min - Mating | 4.064 um |
| Polarized to Mating Part | Yes |
| Material - Plating Mating | Tin |
| Flammability | 94 V to 0 |
| Material - Plating Termination | Tin |
| Circuits (Loaded) | 13 |
| UL | E29179 |
| Keying to Mating Part | None |
| Glow-Wire Capable | No |
| Polarized to PCB | No |
| First Mate / Last Break | No |
| Component Type | PCB Header |
| Material - Resin | Nylon |
| Package Quantity | 1 |
