Conector de placa, 14 contactos, 1 fila, hembra, recto, paso de 0.079 pulgadas, terminal de engarce.
| Color | Natural |
|---|---|
| Application | Signal, Wire-to-Board |
| Series | 35023 |
| Standards | CSA Certified, UL E29179 |
| Max. Temp. | 105 deg C |
| Material | Nylon |
| Hole Center to Center | 2 mm |
| Flammability Rating | UL 94V-0 |
| Number of Rows | 1 |
| Number of Contacts | 14 |
| Glow-Wire Capable | No |
| Stackable | No |
| Product Name | Board-in |
| Pitch - Mating Interface | 2 mm |
| Temperature Range - Operating | -40° to +105°C |
| CSA | LR19980 |
| Material - Resin | Nylon |
| Flammability | 94 V to 0 |
| UL | E29179 |
| Circuits (maximum) | 14 |
| Package Quantity | 1 |
