Conector de placa, 14 contactos, 2 filas, hembra, ángulo recto, paso de 0.1 pulgadas, terminal de soldadura.
| Color | Black |
|---|---|
| Max. Voltage | 350 V |
| Application | Board-to-Board, Signal |
| Series | 90152 |
| Standards | CSA Certified |
| Material | Polyester |
| Max. Temp. | 125 deg C |
| Hole Center to Center | 2.54 mm |
| Terminal Type | Through Hole |
| Contact Finish | Tin Plated |
| Terminal Finish | Tin Plated |
| Contact Plating Thickness | 1.016 µm |
| Number of Contacts | 14 |
| Current Rating | 3 A |
| Number of Rows | 2 |
| Keying to Mating Part | None |
| Plating min - Mating | 1.016 um |
| Pitch - Mating Interface | 2.54 mm |
| Glow-Wire Capable | No |
| Grounding to PCB | No |
| Material - Plating Mating | Tin |
| Current - Maximum per Contact | 3 A |
| Component Type | PCB Receptacle |
| Lock to Mating Part | No |
| Material - Metal | Phosphor Bronze |
| CSA | LR19980 |
| Circuits (Loaded) | 14 |
| PCB Retention | None |
| Material - Plating Termination | Tin |
| Orientation | Right Angle |
| Product Name | C-Grid III |
| Polarized to PCB | No |
| Guide to Mating Part | No |
| Material - Resin | Polyester |
| PCB Thickness - Recommended | 1.6 mm |
| PC Tail Length | 2.9 mm |
| Temperature Range - Operating | -55° to +125°C |
| PCB Locator | No |
| Package Quantity | 1 |
