Conector de tarjeta, 16 Contactos, 1 Fila, Macho, Recto, Paso de 0.1 pulgadas, Terminal de soldadura, Rojo.
| Color | Natural |
|---|---|
| Max. Voltage | 500 V |
| Standards | CSA Certified, UL E29179 |
| Max. Temp. | 235 deg C |
| Material | Nylon |
| Hole Center to Center | 2.54 mm |
| Terminal Type | Through Hole |
| Terminal Finish | Tin Plated |
| Contact Plating Thickness | 0.508 µm |
| Current Rating | 4 A |
| Flammability Rating | UL 94V-0 |
| Contact Finish | Gold Plated |
| Number of Contacts | 16 |
| Number of Rows | 1 |
| Package Quantity | 1 |
