Conector de tarjeta, 22 contactos, 1 fila, macho, recto, paso de 0.156 pulgadas, terminal de soldadura.
| Color | Black |
|---|---|
| Max. Voltage | 250 V |
| Standards | CSA Certified, UL E29179 |
| Hole Center to Center | 3.96 mm |
| Terminal Type | Through Hole |
| Max. Temp. | 235 deg C |
| Material | Polyester |
| Features | Breakaway |
| Number of Contacts | 22 |
| Current Rating | 7 A |
| Flammability Rating | UL 94V-0 |
| Number of Rows | 1 |
| Contact Finish | Tin Plated |
| Package Quantity | 1 |
