Board Connector, 38 Contact(S), 2 Row(S), Female, Straight, 0.079 Inch Pitch, Surface Mount
| Color | Black |
|---|---|
| Max. Voltage | 125 V |
| Application | Board-to-Board, Signal |
| Series | 87368 |
| Standards | CSA Certified, UL E29179 |
| Material | Nylon |
| Hole Center to Center | 2 mm |
| Max. Temp. | 265 deg C |
| Terminal Type | Surface Mount |
| Contact Plating Thickness | 0.381 µm |
| Number of Contacts | 38 |
| Current Rating | 1 A |
| Flammability Rating | UL 94V-0 |
| Terminal Finish | Tin Plated |
| Number of Rows | 2 |
| Contact Finish | Gold Plated |
| Temperature Range - Operating | -55° to +105°C |
| UL | E29179 |
| Lock to Mating Part | None |
| Max-Duration | 14 |
| Durability (mating cycles max) | 25 |
| Max-Cycle | 1 |
| Orientation | Right Angle |
| Material - Plating Mating | Gold |
| Glow-Wire Capable | No |
| Circuits (Loaded) | 38 |
| Current - Maximum per Contact | 1 A |
| Product Name | Milli-Grid |
| Polarized to PCB | Yes |
| PCB Locator | Yes |
| Flammability | 94 V to 0 |
| Max-Temp | 265 |
| Material - Plating Termination | Tin |
| PCB Retention | Yes |
| Material - Resin | Nylon |
| Plating min - Mating | 0.381 um |
| Material - Metal | Phosphor Bronze |
| CSA | LR19980 |
| Pitch - Mating Interface | 2 mm |
| Component Type | PCB Receptacle |
| Package Quantity | 1 |
