Conector de placa, 4 contactos, 2 filas, macho, ángulo recto, paso de 0.165 pulgadas, terminal de soldadura.
| Color | Black |
|---|---|
| Max. Voltage | 600V AC/DC |
| Standards | CSA Certified, UL E29179 |
| Features | Surface Mount Compatible |
| Max. Temp. | 240 deg C |
| Material | High Temperature Thermoplastic |
| Terminal Type | Through Hole |
| Hole Center to Center | 4.2 mm |
| Number of Rows | 2 |
| Contact Plating Thickness | 2.54 µm |
| Number of Contacts | 4 |
| Flammability Rating | UL 94V-0 |
| Terminal Finish | Tin Plated |
| Current Rating | 13 A |
| Contact Finish | Tin Plated |
| Package Quantity | 1 |
