Board Connector, 40 Contact(S), 2 Row(S), Male, Right Angle, 0.079 Inch Pitch, Solder Terminal,
| Color | Black |
|---|---|
| Max. Voltage | 125 V |
| Standards | CSA Certified, UL E29179 |
| Terminal Type | Through Hole |
| Max. Temp. | 265 deg C |
| Features | Surface Mount Compatible |
| Material | High Temperature Thermoplastic |
| Hole Center to Center | 2 mm |
| Current Rating | 2 A |
| Flammability Rating | UL 94V-0 |
| Terminal Finish | Tin Plated |
| Contact Finish | Gold Plated |
| Number of Rows | 2 |
| Contact Plating Thickness | 0.381 µm |
| Number of Contacts | 40 |
| Package Quantity | 1 |
