Conector de placa, 5 contactos, 1 fila, hembra, ángulo recto, paso de 0.1 pulgadas, terminal de soldadura, enchufe.
| Color | Natural |
|---|---|
| Max. Voltage | 500 V |
| Standards | CSA Certified, UL E29179 |
| Terminal Type | Through Hole |
| Material | Nylon |
| Max. Temp. | 235 deg C |
| Hole Center to Center | 2.54 mm |
| Current Rating | 2.5 A |
| Number of Rows | 1 |
| Contact Finish | Gold Plated |
| Number of Contacts | 5 |
| Contact Plating Thickness | 0.508 µm |
| Terminal Finish | Gold Plated |
| Flammability Rating | UL 94V-0 |
| Package Quantity | 1 |
