Conector de tarjeta, 50 contactos, 2 filas, macho, ángulo recto, paso de 0.079 pulgadas, terminal de soldadura.
| Color | Black |
|---|---|
| Max. Voltage | 125 V |
| Standards | CSA Certified, UL E29179 |
| Features | Surface Mount Compatible |
| Terminal Type | Through Hole |
| Material | Nylon |
| Max. Temp. | 265 deg C |
| Hole Center to Center | 2 mm |
| Number of Contacts | 50 |
| Contact Finish | Gold Plated |
| Number of Rows | 2 |
| Flammability Rating | UL 94V-0 |
| Contact Plating Thickness | 0.381 µm |
| Terminal Finish | Tin Plated |
| Current Rating | 2 A |
| Package Quantity | 1 |
