Conector de placa, 6 contactos, 1 fila, macho, recto, paso de 0.059 pulgadas, terminal de montaje en superficie.
| Color | Black |
|---|---|
| Max. Voltage | 250V AC/DC |
| Standards | CSA Certified, UL E29179 |
| Hole Center to Center | 1.5 mm |
| Max. Temp. | 105 deg C |
| Terminal Type | Surface Mount |
| Material | Nylon |
| Contact Plating Thickness | 2.54 µm |
| Number of Contacts | 6 |
| Terminal Finish | Tin Plated |
| Number of Rows | 1 |
| Contact Finish | Tin Plated |
| Flammability Rating | UL 94V-0 |
| Current Rating | 2.5 A |
| Package Quantity | 1 |
