Board Connector, 6 Contact(S), 2 Row(S), Female, Right Angle, Solder Terminal
| Application | Board-to-Board, Signal |
|---|---|
| Series | 90152 |
| Temperature Range - Operating | -55° to +125°C |
| Product Name | C-Grid III |
| CSA | LR19980 |
| Lock to Mating Part | No |
| Voltage - Maximum | 350V AC/DC |
| Circuits (Loaded) | 6 |
| PCB Thickness - Recommended | 1.6 mm |
| Termination Interface Style | Through Hole |
| Material - Metal | Phosphor Bronze |
| Polarized to PCB | No |
| Guide to Mating Part | No |
| Polarized to Mating Part | Yes |
| Number of Rows | 2 |
| PC Tail Length | 2.9 mm |
| Orientation | Right Angle |
| Pitch - Mating Interface | 2.54 mm |
| Grounding to PCB | No |
| Material - Plating Mating | Gold |
| PCB Locator | No |
| Color - Resin | Black |
| Component Type | PCB Receptacle |
| Material - Plating Termination | Tin |
| Stackable | No |
| Plating min - Mating | 0.381 um |
| Durability (mating cycles max) | 100 |
| Glow-Wire Capable | No |
| Material - Resin | Polyester |
| Keying to Mating Part | None |
| Current - Maximum per Contact | 3 A |
| PCB Retention | None |
| Package Quantity | 1 |
