Conector de placa, 7 contactos, 1 fila, hembra, recto, paso de 0.1 pulgadas, terminal de soldadura.
| Color | Black |
|---|---|
| Max. Voltage | 500 V |
| Application | Power, Board to-Board |
| Series | 44812 |
| Standards | CSA Certified, UL E29179 |
| Features | Surface Mount Compatible |
| Material | High Temperature Thermoplastic |
| Max. Temp. | 250 deg C |
| Hole Center to Center | 2.54 mm |
| Terminal Type | Through Hole |
| Flammability Rating | UL 94V-0 |
| Contact Finish | Tin Plated |
| Terminal Finish | Tin Plated |
| Number of Rows | 1 |
| Number of Contacts | 7 |
| Contact Plating Thickness | 5.08 µm |
| Current Rating | 5 A |
| Material - Plating Mating | Tin |
| Component Type | PCB Receptacle |
| Orientation | Vertical |
| Current - Maximum per Contact | 5 A |
| UL | E29179 |
| Flammability | 94 V to 0 |
| Max-Duration | 5 |
| Product Name | KK 254 |
| Plating min - Mating | 5.08 um |
| CSA | LR19980 |
| PCB Retention | None |
| Temperature Range - Operating | See Product Specification |
| Material - Metal | High Performance Alloy |
| Polarized to PCB | No |
| Circuits (Loaded) | 7 |
| PCB Locator | No |
| PCB Thickness - Recommended | 1.6 mm |
| Glow-Wire Capable | No |
| Durability (mating cycles max) | 25 |
| Pitch - Mating Interface | 2.54 mm |
| Max-Temp | 250 |
| Material - Plating Termination | Tin |
| Material - Resin | High Temperature Thermoplastic |
| Package Quantity | 1 |
