Board Connector, 7 Contact(S), 1 Row(S), Female, Straight, Crimp Terminal, Latch, Natural Insulator
| Application | Power, Wire to-Board |
|---|---|
| Series | 35156 |
| CSA | LR19980 |
| Gender | Receptacle |
| Circuits (maximum) | 7 |
| Number of Rows | 1 |
| Flammability | 94 V to 0 |
| Breakaway | No |
| Pitch - Mating Interface | 3.96 mm |
| Color - Resin | Natural |
| UL | E29179 |
| Glow-Wire Capable | No |
| Stackable | No |
| Material - Resin | Polyester |
| Lock to Mating Part | Yes |
| Keying to Mating Part | None |
| Temperature Range - Operating | -40° to +105°C |
| Package Quantity | 1 |
